| Power Source |
AC: 120 V or 230 V, 50/60 Hz |
|
DC: 24 V/7.5 A (VM-2120), 24 V/15 A (VM-2240), M3.5 screw |
|
terminal, Barrier distance: 8 mm, Applicable cable gauge: |
|
AWG22 –AWG14 |
| Power Consumption on AC Mains |
54 W(With no signal present) |
| Current Consumption on 24 V DC Power Input |
1 A(With no signal present) |
| Frequency Response |
50 Hz – 16 kHz |
| Distortion |
1% or less |
| Signal-to-Noise Ratio |
60 dB or more |
| Tone Control |
Bass: 100 Hz ±10 dB, Treble: 10 kHz ±10 dB |
|
(Inputs 1 – 3 and BGM individually adjustable.) |
| Remote Microphone/Expansion Amplifier Connection |
2 RJ45 female connectors for connecting the RM-200M Remote |
|
Microphone and the VM-2120 or VM-2240 unit used as an expansion amplifier. |
|
Maximum distance: 800 m in total |
|
Link cable: Category 5 Shielded Twisted-P air straight |
|
cable (TIA/EIA-568A standard) |
|
Number of connectable RM-200M’s: Up to 4 |
| Input |
Inputs 1 – 3:–60 dB*1 (MIC)/–10 dB*1 (LINE) (changeable), 600 Ω, electronically balanced*2, combined XLR connector (female)/phone jack (Only Input 1 is additionally equipped with DIN connector*3.) |
|
Telephone Paging Input: Push-in terminal block*4 |
|
Voice sound: –10 dB*1, 10 kΩ, electronically-balanced input with shield terminal*2 |
|
Control: No-voltage make contact input, open voltage: 3.3 V |
|
DC, short-circuit current: under 1 mA |
| Control Input |
For controlling Inputs 1 – 3, Push-in terminal block |
|
No-voltage make contact input, open voltage: 3.3 V DC, short-circuit |
|
current: under 1 mA or less |
| Control Input and Output |
D-sub connector (25-pin, female) |
|
Input: No-voltage make contact input, open voltage: 3.3 V DC,short-circuit current: 1 mA or less |
|
Output: Open collector output, withstand voltage: 30 V DC, control |
|
current: 10 mA or less |
|
(1) External control input |
|
Activation of messages*6 |
|
Activation of power |
|
Activation and stop of Emergency Broadcast |
|
Unit’s broadcast cutoff (when activated by an external emergency equipment) |
|
(2) Status output |
|
Irregularity of communications with the Remote Microphone and an expansion amplifier |
|
AC power condition |
|
DC power condition |
|
Irregularity of the sound source of the Voice Announcement Board |
|
Failure (FAULT) indication on |
|
Power switch on |
| External Attenuator Control Output |
Plug-in screw connector*5, relay, no-voltage make contact output, |
|
transfer type, withstand voltage: 30 V DC, 125V AC, contact current: |
|
7 A (DC) or less, 7 A (AC) or less |
| Surveillance Input and Output (*9) |
D-sub connector (25-pin, female) |
|
Input: No-voltage make contact input, open voltage: 3.3 V DC, |
|
short-circuit current: 1 mA or less |
|
Output: Open collector output, withstand voltage: 30 V DC, |
|
operating current: 10 mA or less |
| Power Supply |
24 V DC/0.1 A, for supplying power to an optional Amplifier Control Unit RU-2001/-2002, push-in terminal block* |
| Chine Tone |
Built-in chime: 2-tone chime/2-tone chime (fast repeat)/4-tone chime |
|
(Up)/Single-tone chime/ 4-tone chime (Up & Down)/off |
|
Voice Announcement Board sound source: Pre-recorded chime*6 |
| Function |
Two units stacking (VM-2120 or VM-2240) Emergencya broadcast (sequential control) Broadcast priority control |
|
Surveillance (failure detection) function Power supply to only one Remote Microphone (RM-200M) |
|
Line resistance: 40 Ω (one way) or less |
| Operating Temperature |
0 – 40 °C |
| Finish |
Panel: ABS resin, dark gray (PANTONE 447C or its equivalent), paint |
|
Case: Steel plate, dark gray (PANTONE 446C or its equivalent), paint |
| Dimensions |
419 (w) x 143.3 (h) x 355.7 (d) mm |
|
|
